Specifications
- Family:FXDx
- Model Type: Ducted
- Nominal Capacity: 12000 Btu/h
- Cooling Capacity: 11500 Btu/h
- Heating Capacity: 11500 Btu/h
- Fan Air Flow Rate: 280 ft³/min
- External Static Pressure: 0.12 in
- Sound Pressure Level: 33 dBA
- Minimum Circuit Ampacity: 8.75 A
- Maximum Overcurrent Protection: 15 A
- Frequency: 60 Hz
- Voltage: 230 V
- Weight: 47 lb
Dimensions- Height: 7-7/8 in
- Width: 27-9/16 in
- Depth: 24-7/16 in
- Pipe Connections - Liquid: 1/4 in
- Pipe Connections - Gas: 3/8 in
- Pipe Connections - Drain: 23/32
Application
- Hotel Rooms
- Multi-Family Residences
- Single-Family Residences
- School Dormitories
Features
- The slim height, at only 7-7/8'', makes it suitable for most of the applications where attic / bulkhead space is limited
- With a sound level as low as 31 dBA, these systems are among the quietest on the market
- Washable filter included
- Built-in condensate pump
- Blends unobtrusively with any interior decor; only the suction and discharge grills are visible
- Standard Limited Warranty: 12-year warranty on compressor and all parts
Cooling Capacity
Nominal cooling capacities are based on the following conditions:- Return air temperature: 80 ºFDB, 67 ºFWB
- Outdoor temperature: 95 ºFDB
- Equivalent ref. piping length: 25 ft / 7.5 m (Horizontal)
Heating Capacity
Nominal heating capacities are based on the following conditions:
- Return air temperature: 70 ºFDB.
- Outdoor temperature: 47 ºFDB, 43 ºFWB
- Equivalent ref. piping length: 25 ft / 7.5 m (Horizontal)
